The Ford Bronco Raptor runs a 3.0L EcoBoost V6 with two turbochargers strapped to it, not a V8. That surprises a lot of people, especially anyone who is cross-shopping between the F-150 Raptor R, which does run a supercharged V8. The two trucks share the same name and attitude, but not the same engine.
What Engine Does the Ford Bronco Raptor Have?
If you have a Bronco Raptor, you likely have a 3.0L twin-turbo EcoBoost V6, making around 418 horsepower and 440 lb-ft of torque. Those aren't some light numbers. It is the same basic engine architecture used in the Explorer ST and Lincoln Aviator, heavily reworked for the Raptor with a stronger block, upgraded turbos, and a cooling system that was designed and built to survive sustained high-speed desert running.
This is the only engine option on the Raptor trim. Most other Bronco trims have a 2.3L four-cylinder and a 2.7L V6 option. The Raptor skips that choice and gives you the 3.0L standard, no other option available.
Does the Ford Bronco Raptor Have a V8?
It does not! This is probably the single most searched question about this truck's engine, and the answer genuinely surprises people. The Raptor name gets attached to V8 trucks often enough (the F-150 Raptor R runs a supercharged 5.2L V8) that plenty of buyers assume the Bronco version follows the same formula. It does not.
Ford built the Bronco Raptor around a twin-turbo V6 intentionally. A V8 tends to be heavier, sits differently in the engine bay, and changes the truck's balance in a way that works against what the Raptor was designed to do, which is fly across the desert at high speeds while staying pretty much leveled. The V6 keeps the front end lighter and lets the suspension do more of the work.
Is There a V8 Bronco Raptor?
Not from Ford, but yes, from a pretty popular tuner. Hennessey builds a supercharged V8 conversion for the Bronco Raptor called the VelociRaptor. Pretty cool name, right? It swaps in a supercharged 5.0L Coyote V8 pulled straight from the Mustang lineup, backed by Hennessey's own tuning and suspension work. The Horsepower numbers on these builds tend to run well past the 500s, depending on whatever package Hennessey sells that year.
This is just a full aftermarket conversion done after the truck leaves the factory, not something Ford offers or supports under warranty. So if a V8 is a dealbreaker for you, the Hennessey route exists, but it costs a lot more on top of the factory truck and voids your factory powertrain warranty in the process.
How Much Horsepower and Torque Does the Bronco Raptor Make?
418 horsepower and 440 lb-ft of torque, both figures higher than any other Bronco trim by a wide margin. For comparison, the 2.7L EcoBoost V6 available on other trims makes 330 horsepower and 415 lb-ft. The Raptor adds nearly 90 horsepower on top of that while running a similar displacement, which comes down to the turbo sizing, a reinforced block that can handle more boost, and an intercooler setup built specifically for this application.
Torque delivery on the Raptor also comes in earlier in the rev range than the 2.7L, which matters more on the trail than the horsepower number does. Most of what you feel climbing a loose grade or powering out of sand comes from torque available at low RPM, not peak horsepower at the top of the tach.
What Makes the Raptor's 3.0L Different From the Bronco's Other Engines?
The displacement number looks close to the 2.7L, but the internals are not the same engine scaled up slightly. Call it the ford bronco raptor motor or the raptor bronco motor, either way the internals are what set it apart from a standard 3.0L: larger turbochargers, a stronger forged crankshaft, and a dedicated cooling package that includes a larger radiator and additional oil cooling capacity. Ford built this specifically to handle sustained high-load running, the kind of driving where you are holding higher RPM for extended periods across rough terrain, which is a very different demand than a daily commute or the occasional trail weekend most 2.7L owners put their truck through.
The transmission pairing is different too. The Raptor's 3.0L only comes backed by a 10-speed automatic. There is no manual option on this trim, same as the 2.7L on other trims. If a manual matters to you, the 2.3L is your only path to that in the Bronco lineup, and it is not available on the Raptor at all.
Does the Raptor's Engine Hold Up Off-Road?
Yes, and that is largely the point of the extra cooling hardware. Desert running at sustained speed generates far more heat than rock crawling at low speed, since the engine is working harder for longer stretches without the cooling breaks that come from slow, technical terrain. Ford engineered the Raptor's cooling system around that specific use case rather than adapting a standard EcoBoost cooling setup and hoping it held up.
Real-world reports from Raptor owners running desert routes and high-speed sand tend to confirm this holds up as designed, without the heat soak issues that show up on trucks running cooling systems sized for on-road use pushed into conditions they were not built for.
If you are building out a Raptor for serious desert or trail use, protecting what is underneath the engine matters just as much as what the engine itself can handle. We cover the specific undercarriage components worth protecting, and which ones actually matter for how hard you run the truck, in our full guide to Ford Bronco skid plates.
Ford Bronco Raptor Engine FAQ
What year did the Ford Bronco Raptor get its engine?
The Bronco Raptor launched for the 2022 model year with the 3.0L twin-turbo EcoBoost V6 as its only engine option, and that has remained unchanged through every model year since.
Is the Bronco Raptor's engine the same as the Explorer ST?
It shares the same basic 3.0L twin-turbo V6 architecture, but Ford reworked it for the Raptor with different turbo sizing, a reinforced internal structure, and a cooling system built for sustained off-road use rather than street driving.
Can you put a V8 in a Ford Bronco Raptor?
Not from Ford. Hennessey offers an aftermarket supercharged V8 conversion for the Bronco Raptor called the VelociRaptor, which swaps in a supercharged 5.0L Coyote V8. It costs a lot more on top of the truck itself and voids your factory powertrain warranty.
How much horsepower does the Bronco Raptor engine make?
418 horsepower and 440 lb-ft of torque from the factory 3.0L twin-turbo V6. That is the highest output of any engine in the Bronco lineup.
Does the Bronco Raptor come with a manual transmission?
No. The Raptor's 3.0L only pairs with a 10-speed automatic. The 7-speed manual is only available on the 2.3L on other Bronco trims and is not offered on the Raptor at all.
For the full breakdown of how the 2.3L and 2.7L compare to each other on every other Bronco trim, read our Ford Bronco 2.3L vs 2.7L engine guide.
